2021 Giant Momentum Transend E+ Electric Bicycle
2021 Giant Momentum Transend E+ Electric Bicycle
A New Way to Move
The all-new Transend E+ e-bike is a smart transportation solution that’s way more fun than a train or a bus. Featuring our SyncDrive Life motor and an integrated battery pack, this electric commuter bike gives you a seamless boost of pedaling power so you can ride farther and faster with less effort. You can choose lower support modes for fitness rides, or more support when you want to get across town without breaking a sweat. The Giant E-bike app makes it easy to access navigation functions, fitness info and support modes. It’s everything you need to make daily transportation the best part of your day.
Take a Test Drive Today
Kick off a new commuting routine that’s adventurous, healthy and more fun than a train or a bus. Transend E+ is made with our SyncDrive Life motor and an integrated battery pack, giving you a seamless boost of pedaling power so you can ride farther and faster with less effort.
Specifications
| HYBRID CYCLING TECHNOLOGY | |
|---|---|
| MOTOR | Giant SyncDrive Life |
| SENSORS | Giant PedalPlus 6-sensor technology |
| DISPLAY | Giant RideControl One |
| BATTERY | Giant EnergyPak 500Wh |
| FRAME | |
| SIZES | S, M, L |
| COLORS | 2 color |
| FRAME | ALUXX aluminium, Double Diamond |
| FORK | ALUXX aluminium |
| COMPONENTS | |
| HANDLEBAR Aluminium | 12D sweep back, rise 25 mm, 720 width, TR48A-00S1 |
| STEM | TDS-807-8 FOV 31.8 |
| SEATPOST | Aluminium 30.9mm |
| SADDLE | Selle Royal Essenza Moderate |
| PEDALS | Anti-slip |
| DRIVETRAIN | |
| SHIFTERS | NEXUS 7 RevoShift, SL-C3000-7 |
| FRONT DERAILLEUR | N/A |
| REAR DERAILLEUR | N/A |
| BRAKES | Tektro HD-C275 hydraulic disc brake, 160mm |
| BRAKE | LEVERS Tektro HD-C275 Hydraulic Disc |
| CASSETTE | 18 T |
| CHAIN KMC | Z1eHX NP/NP |
| CRANKSET | Giant Crank |
| WHEELS | |
| RIMS | 27.5 aluminum, e-bike optimized |
| HUBS | Shimano Nexus 7, SG-C3001-7D rearShimano TX505 front |
| SPOKES | Stainless steel |
| TIRES | Kenda Kwick Seven.5 27.5" x 2.20 |
| EXTRAS | Giant EnergyPak 6A charger, Alloy Kickstand |
Geometry
| Frame | Small | Medium | Large |
|---|---|---|---|
| Seat Tube Length (inch) | 15.7 | 18.5 | 21.5 |
| Seat Tube Angle | 73.0° | 73.0° | 73.0° |
| Top Tube Length (inch) | 22.2 | 22.8 | 24.2 |
| Head Tube Length (inch) | 5.5 | 5.9 | 6.5 |
| Head Tube Angle | 69.5° | 69.5° | 69.5° |
| Fork Rake (inch) | 2 | 2 | 2 |
| Wheelbase (inch) | 44 | 44.6 | 46 |
| Chain Stay Length (inch) | 19.1 | 19.1 | 19.1 |
| Bottom Bracket Drop (inch) | 2.4 | 2.4 | 2.4 |
| Stack (inch) | 22.9 | 23.2 | 23.8 |
| Reach (inch) | 15.5 | 15.9 | 17.2 |
| Stand Over Height (inch) | 28 | 29.8 | 31.9 |
| Handlebar Width (inch) | 28.3 | 28.3 | 28.3 |
| Stem Length (inch) | 2.4 | 2.4 | 3.1 |
| Wheel Size | 27.5 | 27.5 | 27.5 |
